Especificaciones de montaje en cochera
Installation Site : Open ground
Installation Angle: 3 ° - 1 5 °
Building Height: 2.0~3.5m
Wind Load: Up to 60m/s
Snow Load: Up to 1.4KN/m2
PV Modules: Framed or Frameless Panel
Module Orientation: Horizontal or vertical
Module Width: Any Size
Standard: BS EN 1991-1-4:2005
Warranty: 5 years on material
Products Strengths of Sunforson technology
1 . Quick installation: It is quite easy and fast installation without any welding. Save onsite installation time
2. Professional design, lower costs: Products were designed by the experienced designers w ho are very professional on the systematic design, stable structure mature technology . The design can meet the BS EN 1991-1-4:2005 and save cost for the customers.
3. Load design, Safety Guarantee: Sunforson PV bracket system design take s full account of component weight, combine factors of wind snow and earthquake load, dynamic load and static load, they have long-term performance and high load capacity in practical applications.
4. Beautiful Appearance: In order to make SunRack Carport become a beautiful building, the bracket system adopt s the unique rail design, it can also have a good rain proof performance if needed .
